EV Charging Cable 32A Adjustable Electric Car Charger 7kw Type 1 Portable EV Charger
This home charger has been given IP 66 class, which distinguishes it from other mobile charging stations. In concrete terms, this means that the mobile charger can withstand 100 liters of water per minute. One of the biggest advantages of this charger is the charging speed which is fully adjustable from 1.4 kW to 3.7 kW. This means that the mobile charger can also be connected to a group to which, for example, a refrigerator or washing machine is already connected; then you just lower the charging speed. Is the group empty or are no other devices used at night? Then set the charging speed to maximum.
Product Name | SAE J1772 Model 2 Charger |
Length | 5m or customized length |
Rated current | 32A: 16A/26A/32A |
Operation Volatge | 250V |
Insulation resistance | more than 500M Ohm(DC500V) |
Contact resistance | 0.5m Ohm max |
Terminal temperature rise | less than 50K |
Withstand voltage | 1500V |
Mechanical life | no-load plug in/out more than 10000 times |
Coupled insertion force | 45N~100N |
Impact of external force | can afford 1M drop |
Operating Temperature | -30~+50ºC |
Case material | thermoplastic, flame retardant grade UL94 V-0 |
Termminal | Copper alloy , silver plating |
Control box function | leakage protection; |
overvoltage under-voltage protection; | |
over load protection; | |
lightning protection; | |
ground protection; | |
over-temperature protection; | |
Features | Easy: Charge at home, at work, or anywhere with the socket. No installation is required, just an intuitive pairing process. Plug and charge, wherever you are; |
Safe: Protecting Earthing detection; | |
Designed for electric cars using the SAEJ1772 standard, this car charger offers a maximum charging speed of 3.6 kW per hour. The precision engineering of the internal circuit board allows automatic detection and correction of any problems during charging, including any issues with minimal, unstable, or excessive voltage, current, frequency, earth leakage, and temperature even during lightning and electrical storms. |
Characteristic:
1.Lightning protection
2.Over-voltage protection
3.Leakage protection
4.Over-load protection
5.Waterproof IP66
Q1: Rated current
A: Fixed current : 16A 32A
Adjustable current : 16A: 8A/10A/13A/16A
32A: 16A/26A/32A
Q2: Earth setting
A: We have 2 options for your reference. YES grounding means earthing is on. No grounding means earthing is off.
Q3: Delivery time
A: Sample time is within 3 days.
Bulk order is 7-10 working days.
Q4: Warranty
A: 1 year.
Q5. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 7-10 days to arrive. Airline and sea shipping also optional.
Q6. How to proceed an order for EV charging cables?
A: 1) let us know your requirements or application.
2) We quote according to your requirements or our suggestions.
3) Customer confirms the samples and places deposit for formal order.
4) We arrange the production.
Q7. Is it OK to print my logo on the products?
A: Yes. Please inform us formally before our production.
Q8: How to deal with the faulty?
A: 1)Our products are produced in strict quality control system and the defective rate will be less than 0.5%.
2)During the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
